SF1xxx Base Runtime

The SF100x can be used via the EtherCAT bus to collect the I/O status and deliver commands according to the task setting cycle. Configurable management can be performed in the SE1xxx development environment.

EtherCAT IO redundancy is implemented, and if one of the IO modules fails, the EtherCAT data packets are automatically looped back according to the EtherCAT network topology principle.

C/C++ Runtime

SF101x includes PLC, C++, Simulink runtime, SF101x can be used to implement one or more PLCs on the industrial machine for logic processing, users can choose the international standard IEC 61131-3 to achieve PLC programming and debugging, can also choose C/C++ for programming and debugging, and can also run Simuink® exported models.

Scope Data Oscilloscope Local data storage

If one of the machine fails, the other machine will automatically enter the takeover state and take over all the control functions of the main machine.

Scope Data Oscilloscope, TCP Communication, Remote Storage

Scope Data Oscilloscope IOT Remote storage
